ELITE 3rd Gen | LED Cloud Pane
ELITE 3rd Gen | LED Cloud Pane
ELITE 3rd Gen | LED Cloud Pane
ELITE 3rd Gen | LED Cloud Pane
ELITE 3rd Gen | LED Cloud Pane

ELITE 3rd Gen | LED Cloud Pane

Adj Watt 30W/40W/50W/60W/72W · Adj CCT 3000K/3500K/4000K/5000K/6500K · 2'×4'

Watt: 30W/40W/50W/60W/72W Lumens: Varies with Design CCT: 3K/3500K/4K/5K/6500K Rating: ETL Listed
★★★★★ 4.8 · 42 reviews
MSRP: $119.95
PRICE PER PIECE
$89.95
You save $30.00
Contractor, distributor, or reseller? Log in for trade pricing »
Min order: 4 per box
×

The product SKU is: 157110

✓ Free shipping on all Orders
✓ Ships from Stone Mountain, GA — most orders ship in 1 business day
✓ 30-day returns · 5-year warranty · ETL Listed
Want to Buy in bulk ?

Contact us for volume pricing or become a trade partner.

Contact Team Become Partner

Product Description

Beyond LED Technology's ELITE 3rd Gen in 2'×4' brings the cloud panel format to larger commercial zones where longer fixture runs and higher wattage output are needed. At up to 72W across five field-selectable settings, it covers open offices, corridors, healthcare wings, and hospitality common areas that the 2'×2' variant cannot serve at adequate footcandle levels. Five CCT options spanning warm to daylight white allow a single SKU to be tuned across varied room types within the same project. Slim metal construction, built-in earthquake clips, and 0–10V dimming round out a fixture suited to both new construction and retrofit ceiling applications.

Key Features

  • Cloud panel design
  • Adjustable CCT — field selectable
  • Adjustable wattage — field selectable
  • CRI >80
  • 120° beam angle
  • 0–10V dimmable
  • Built-in earthquake clips
  • Super slim metal construction
  • Input voltage 100–277VAC
  • 2'×4' fixture size
  • ETL Listed
  • 5-year warranty

Applications

Open Workspaces Healthcare Corridors Hospitality Areas Educational Spaces Seismic Installations Ceiling Retrofits

Specifications

SKU 157110
Wattage 30W/40W/50W/60W/72W
CCT 3K/3500K/4K/5K/6500K
Lumens Varies with Design
Input Voltage 100-277V
Size 2'×4'
CRI >80
Construction Metal
PCS/BOX 4 PCS/BOX
Construction Metal
Light Spread 120°
Dimming 0–10V
Certification ETL Listed
Warranty 5 Years

Downloads

Spec Sheet PDF
LM80 Report PDF

Need help?

Talk to a lighting specialist about project pricing, photometrics, or custom requirements.

866-786-1117
sales@beyondledtechnology.com
— FAQ —

Frequently Asked Questions

Everything you need to know before specifying ELITE 3rd Gen | LED Cloud Pane into a lighting project.

When should I specify the 2'×4' ELITE 3rd Gen over the 2'×2'?+
The 2'×4' reaches up to 72W versus 40W for the 2'×2', making it better suited for larger zones, longer ceiling runs, and spaces where higher output per fixture reduces total fixture count. Open offices, corridors, and healthcare wings are typical applications where the larger format performs better.
Why does lumen output vary with design on the ELITE 3rd Gen?+
The cloud panel format supports different mounting configurations and orientations that affect spatial light distribution. Wattage and efficacy are the more reliable specification metrics — lumen delivery to the working plane depends on the specific installation layout and ceiling height.
Does the 2'×4' ELITE 3rd Gen work in seismic zones?+
Yes. Built-in earthquake clips secure the fixture to the ceiling structure during seismic activity without additional hardware, meeting seismic retention requirements in California and other seismic zones where ceiling fixture retention is code-mandated.
Can wattage and CCT be adjusted after installation?+
Yes — both are field selectable at the fixture. Five wattage levels and five CCT options can be set during installation without pre-ordering multiple variants, simplifying procurement across projects with varied zones or lighting targets.
How quickly does the ELITE 3rd Gen ship and is trade pricing available?+
Most orders ship within one business day from Beyond LED Technology's Stone Mountain, Georgia warehouse. It ships in cases of 4, and approved trade partners through the Beyond LED Trade Partner Program receive factory-direct trade pricing and dedicated account support.
