How to Lay Out LED Area Lighting for Parking Lots

Are your parking lot lights sufficient enough to keep your property safe, compliant, and cost-efficient after dark? If not, you’re at the right place.

As the night deepens, parking lots become vulnerable and prone to all sorts of risky scenarios. Lack of illumination and visibility can result in accidents, theft, or customer dissatisfaction. That's why designing your LED area lighting layout is not only about compliance - it's about safety, visibility, and professionalism.

Whether you are managing a new commercial complex or retrofitting an existing old lot, outdoor LED lights for parking lots are the ideal solution for reliability, energy efficiency, and long-term performance. In this guide, you will discover how to properly design parking lot LED lights, including pole spacing, recommended fixtures, photometric planning, and compliance advice. So, stop wasting time and money and continue reading this to save yourself time and resources.

Why Parking Lot Lighting Design Matters

Properly planned parking lot lighting design has several benefits:

• Safety

Good lighting enhances visibility for pedestrians and drivers, minimizing the potential for accidents, collisions, and slips.

• Security

Illuminating a lot discourages theft, vandalism, and suspicious behavior, making your employees and customers safer.

• Liability Reduction

Proper lighting reduces your susceptibility to lawsuits and insurance claims related to unsafe conditions.

• Compliance

Local codes and IES guidelines for parking lots usually mandate minimum light levels, uniformity, and mounting positions.

• Curb Appeal

For businesses that stay open late, effective lighting highlights your property and makes guests feel secure.

Parking Lot Lighting Layout: 5 Key Considerations

Before selecting fixtures or doing quantity calculations, take these five key elements into account when designing commercial area light layout:

Pole Height and Spacing

The majority of commercial sites utilize poles ranging from 20 to 30 feet tall. Higher poles require fewer fixtures but need a beam robust enough to stretch all the way to the ground evenly.

Pole Spacing

The standard rule is to space poles between 2 and 2.5 times their height. To illustrate, 25 ft poles should be spaced approximately 50-60 ft apart to have equal coverage.

Beam Angle & Distribution Type

Apply Type III or Type IV distribution for perimeter lighting. Type V is best suited for center-of-lot or square spaces, spreading light in a circular pattern.

Lumens & Wattage

A commercial LED area light must output between 15,000 and 50,000 lumens, depending on lot size and mounting height. For instance:

150W = ~21,000 lumens

300W = ~42,000 lumens

Uniformity Ratio

This reflects the level of average and minimum illumination. The ideal ratio is 3:1, where there are no glare zones or dark areas. IESNA standards suggest an average of 1-2 foot-candles for general lots and 3-5 foot-candles for high-traffic or retail lots.

Sample LED Layouts for Small, Medium & Large Lots

Use these example layouts to design your LED parking lot project by car capacity and lot size:

Pro Tip: Test these configurations virtually prior to installation, using a photometric layout for parking lots. Photometric software illustrates how light will distribute across the lot based on what you input, aiding in both aesthetics and code compliance.

Choosing the Right Area Light Fixtures

All LED area lights for commercial use are not created equal for commercial applications. Select fixtures that adhere to stringent performance, durability, and compliance standards. Prioritize these:

• DLC/UL Certified: Assures the product passes safety and efficiency requirements.
• High Lumens with Wattage Adjustability: Opt for versatile fixtures that enable you to adjust brightness to your needs.
• Type V Distribution: Ideal for symmetrical lighting in central spaces.
• IP66 Weatherproof Rating: Designed for rain, wind, and debris—critical for outdoor installations.
• Dusk-to-Dawn Photocell Compatibility: Installs automatically with ambient light sensitivity.
• Built-in Surge Protection: Prevents destruction during power surges.
• 10-Year Warranty: Long-term project peace of mind.

Checkout the Most Demanding Product: BeamPro Adjustable Area Light

The most feature-rich fixture in the world, the BeamPro+ LED Area Light is a groundbreaking innovation in outdoor lighting space. It also happens to be a top contender for Most Innovative Product of the Year at LightFair International (LFI) 2025. Engineered for unmatched flexibility, performance, and simplicity, BeamPro+ consolidates what would normally require more than 90 SKUs into a single, all-in-one fixture, making it the most feature-rich LED area light on the market today. Features include:

• Up to 160 lm/W
• Adjustable wattage
• Adjustable CCT
• Adjustable Beam Angle by Click of a button Type III / Type IV / Type V
• Optional Screw-in Photocell
• Universal & Yoke Mount included
• Built-in 10KV Surge Protection
• 0-10V Dimmable
• Bronze Housing
• Input Voltage: 120-347 VAC
• UL & DLC Listed
• 7-Year Warranty

More like BeamPro+: ZOHO 6th GEN LED AREA LIGHT

The Zoho 6th Generation Area Light from Beyond LED Technology is a trusted, high-performance outdoor lighting solution, built for durability and designed with a slim, modern profile. Constructed from rugged die-cast aluminum and finished in a sleek bronze housing, the Zoho 6th Gen combines top-tier performance with contemporary aesthetics. Features include:

• Up to 170 lm/W
• Adjustable wattage
• Adjustable CCT
• Optional screw-in photocell
• 0-10V dimmable
• Built-in 10KV surge protector
• Universal bracket included
• White, Black & Bronze housing
• Input voltage 120-277 VAC
• UL & DLC listed
• 5-year warranty

Tips for Installing LED Area Lights in Parking Lots

Your design is only as good as its installation. To ensure the best results, keep these installation tips in mind.

Run a Photometric Simulation

This computer program simulates actual light coverage prior to fixtures' installation.

Avoid Over-lighting

Brightness makes it more expensive and aids in light pollution, particularly in urban areas.

Use Asymmetric Beams Near Edges

Point light in the direction of the lot and away from adjacent buildings or roads.

Mount at 30 Feet for Broad Coverage

Tall poles with broad-angle luminaires minimize the number of poles.

Plan Pole Base Layout Strategically

Account for underground utilities, drive lanes, and parking rows.

A qualified installer or lighting designer can get your pole-mounted LED area lights properly aligned, leveled, and code compliant.

Parking Lot Lighting Layout FAQs

How many lumens are required for a parking lot?

For general application: 20,000–30,000 lumens per fixture. High-traffic or sales areas can require up to 45,000 lumens for increased visibility.

How far apart do parking lot light poles go?

Apply a rule of 2 to 2.5x the mounting height. Therefore, for a 25 ft pole, space poles approximately 50–60 ft apart.

What is a Type III or Type V light distribution?

Type III: Ideal for edges and walkways.

Type V: Even circular distribution - ideal for center-lot spaces or square lots.

Does LED parking lot lighting save energy costs?

Yes! LEDs consume up to 75% less power than conventional HID or metal halide lights—and have a 5–10x longer lifespan. That's huge electricity and maintenance savings.

We are leading experts in energy efficient area lighting space for the commercial market. From product selection to photometric layout planning, our experts provide you with maximum performance with minimal stress.
