ZION 3rd Gen | LED Semi Cutoff Wall Pack
ZION 3rd Gen | LED Semi Cutoff Wall Pack
ZION 3rd Gen | LED Semi Cutoff Wall Pack
ZION 3rd Gen | LED Semi Cutoff Wall Pack
ZION 3rd Gen | LED Semi Cutoff Wall Pack

ZION 3rd Gen | LED Semi Cutoff Wall Pack

Adj Watt 35W/50W/70W · 9,450 Lumens · 5000K · Bronze Housing

Watt: 35W/50W/70W Lumens: 9450Lm CCT: 5000K Rating: UL & DLC Listed IP: IP65
★★★★★ 4.8 · 42 reviews
MSRP: $104.95
PRICE PER PIECE
$89.95
You save $15.00
Contractor, distributor, or reseller? Log in for trade pricing »
Min order: 1 per box
×

The product SKU is: 157087

✓ Free shipping on all Orders
✓ Ships from Stone Mountain, GA — most orders ship in 1 business day
✓ 30-day returns · UL & DLC Listed
Want to Buy in bulk ?

Contact us for volume pricing or become a trade partner.

Contact Team Become Partner

Product Description

Beyond LED Technology's ZION 3rd Gen is a capable, no-nonsense semi cutoff LED wall pack built for commercial and industrial exteriors that need strong, controlled illumination without the strict optical constraints of a full cutoff design. The semi cutoff optic allows a modest degree of upward light that improves vertical surface visibility — practical for building facades, signage walls, and entry points where ambient fill matters. Bridgelux chip technology, die-cast aluminum housing, and IP65 protection deliver reliable long-term performance across demanding outdoor environments. Adjustable wattage keeps energy use matched to the application.

Key Features

  • Up to 135 lm/W efficacy
  • Adjustable wattage — field selectable
  • Fixed CCT: 5000K
  • 0–10V dimmables
  • 100° light spread
  • Semi cutoff optical design
  • PC lens diffuser
  • CRI>80
  • Die-cast aluminum housing
  • Bronze housing finish
  • UL & DLC listed
  • Input voltage 100–277VAC

Applications

Building Facades Entry Points Warehouse Perimeters Feature Walls Parking Perimeters Industrial Exteriors

Specifications

SKU 157087
Wattage 35W/50W/70W
CCT 5000K
Lumens 9450Lm
Input Voltage 100-277Vac
Surge Protection 4KV
CRI >80
Lumen Efficacy Up to 135 lm/W
Power Factor ≥0.9
PCS/BOX 1 PC/BOX
Light Spread 100°
Dimming 0–10V
IP Rating IP65
Certification UL & DLC Listed

Downloads

Spec Sheet PDF
LM80 Report PDF
LM79 Report PDF
IES File IES

Need help?

Talk to a lighting specialist about project pricing, photometrics, or custom requirements.

866-786-1117
sales@beyondledtechnology.com
— FAQ —

Frequently Asked Questions

Everything you need to know before specifying ZION 3rd Gen | LED Semi Cutoff Wall Pack into a lighting project.

What is a semi cutoff wall pack and when is it the right choice? +
A semi cutoff fixture allows a small amount of upward light, improving vertical surface brightness and ambient fill around entry points and facades. It's the right choice when some wall wash effect is desirable alongside downward illumination.
Is the ZION 3rd Gen suitable for building entrances and signage walls? +
Yes. The semi cutoff design and 100° spread make it well suited for entry points, feature walls, and signage areas where both downward coverage and vertical surface visibility matter. The crisp 5000K output keeps signage and facade details sharp and visible.
Can I dim the ZION 3rd Gen? +
Yes. It supports 0–10V dimming, compatible with standard building automation systems and lighting control panels. This allows output to be adjusted based on time of day or occupancy without replacing any hardware.
Will the ZION 3rd Gen qualify for utility rebates? +
UL and DLC listing qualifies it for most US utility rebate programs. Beyond LED Technology provides free photometric layout support within 24 hours for approved trade partners, simplifying rebate documentation on commercial exterior projects.
How durable is the ZION 3rd Gen for year-round outdoor use? +
Die-cast aluminum housing, IP65 weather resistance, and 4KV surge protection make it reliable in coastal, industrial, and high-traffic commercial environments through all seasons.
How quickly does the ZION 3rd Gen ship and is trade pricing available? +
Most orders ship within one business day from Beyond LED Technology's warehouse in Stone Mountain, Georgia. Approved trade partners through the Beyond LED Trade Partner Program receive factory-direct trade pricing and dedicated account support.
